[visionlist] [*Email Suspect*] is this visual illusion already existing?

[Kenneth KNOBLAUCH]

Werner, J. S., Bieber, M. L., & Schefrin, B. E. (2000). Senescence of foveal and parafoveal cone sensitivities and their relations to macular pigment density. Journal of the Optical Society of America A, 17(9), 1518-1532.


Bieber, M. L., Volbrecht, V. J., & Werner, J. S. (1998). Foveal cone photopigment distribution: small alterations associated with macular pigment distribution. Vision Research, 38(21), 3241-3248.


Werner, J. S., Donnelly, S. K., & Kliegl, R. (1987). Aging and human macular pigment density. Vision Research, 27(2), 257-268.


Hammond, B. R., Wooten, B. R., & Snodderly, D. M. (1997). Individual variations in the spatial profile of human macular pigment. Journal of the Optical Society of America A, 14(6), 1187-1196.

___

Kenneth Knoblauch
Inserm U1208
Stem-cell and Brain Research Institute
18 avenue du Doyen Lépine
69500 Bron
France
tel: +33 (0)4 72 91 34 77
fax: +33 (0)4 72 91 34 61
portable: +33 (0)6 84 10 64 10

https://spam.inserm.fr/fmlurlsvc/?fewReq=:B:JVo+NTc0PiJyOTYqNCJtYDk0NT40NSJ3bWNqZXBxdmE5YD0yMDdiYmEzNDYyYWYyNmEyNmJgNGYzNDRiZzBlZjMxZ2YyPDw8MyJwOTUzPD0wNDYxPTUidW1gOTI8QUNDUkN8NDY2PTE2KTI8QUNDUkw1NDY2PTE2InZndHA5Imc5NzcibGBoOTQ=&url=https%3a%2f%2fsbri.fr%2fpublic-profile%2f63%2fsingle-member%2f


________________________________
De : PERRINET Laurent <laurent.perrinet at univ-amu.fr>
Envoyé : lundi 14 septembre 2026 17:59
À : Kenneth KNOBLAUCH
Cc : visionlist at visionscience.com; Etienne Rey
Objet : Re: [*Email Suspect*] [visionlist] is this visual illusion already existing?

Hi Ken

Thanks for the feedback.

The idea is that the two colors are defined by Gaussian densities in the spectral range of visible wavelengths such that:

- both colors have the same mode (~470 nm, see below)
- the background color is narrow (std of 4 nm) while that of the shape is broader (40 nm)
- these colors are normalized to be of the same luminance (relying on the very practical `colormath` package)

In summary, the colors are the same except one (the background) is more precise in spectral space ad the other less (shape).

Your mention of the Maxwell spot is clearly the good direction. It gave me pointers to interesting papers including :

- Marina Gardasevic, Robert J. Lucas, Annette E. Allen Appearance of Maxwell’s spot in images rendered using a cyan primary https://spam.inserm.fr/fmlurlsvc/?fewReq=:B:JVo+NTc0PiJyOTYqNCJtYDk0NT40NSJ3bWNqZXBxdmE5YTJgYGdiZzcxMDVlN2JlYTE3YTEzYTQ8YmBiNTdmMDAzN2ZiPWFlZSJwOTUzPD0wNDYxPTUidW1gOTI8QUNDUkN8NDY2PTE2KTI8QUNDUkw1NDY2PTE2InZndHA5Imc5NzQibGBoOTQ=&url=https%3a%2f%2fwww.sciencedirect.com%2fscience%2farticle%2fpii%2fS0042698919301889

- Akiyoshi Kitaoka  https://spam.inserm.fr/fmlurlsvc/?fewReq=:B:JVo+NTc0PiJyOTYqNCJtYDk0NT40NSJ3bWNqZXBxdmE5NTY2MDZhM2ExZzI1PTJnZzU3MjE1M2JgNT1mN2YwNmUyPTA3YGdiPSJwOTUzPD0wNDYxPTUidW1gOTI8QUNDUkN8NDY2PTE2KTI8QUNDUkw1NDY2PTE2InZndHA5Imc5NzQibGBoOTQ=&url=https%3a%2f%2fwww.psy.ritsumei.ac.jp%2fakitaoka%2fshitsukan-shikikaku2024.html

This paper pointed to a peak wavelength of 460nm (for the blue in OLED displays) which makes the effect a bit different. The notebook explores the range of 460 to 490 nm giving differential effects.


Thanks, Laurent



[GraphiqueCollé-1.png]

Le 14 sept. 2026 à 16:09, Kenneth KNOBLAUCH <ken.knoblauch at inserm.fr> a écrit :

Telln us some more about the spectral characteristics of the stimuli. I suspect that you are seeing the differential filtering by macular pigment in fovea and parafovea, like Maxwell’s spot but sampled discretely.  I am a protanope and see it.

thanks   very cool


ken
Kenneth Knoblauch
Inserm U1208
Stem-cell and Brain Research Institute
18 avenue du Doyen Lépine
69500 Bron
France
tel: +33 (0)4 72 91 34 77
fax: +33 (0)4 72 91 34 61
portable: +33 (0)6 84 10 64 10
http<https://spam.inserm.fr/fmlurlsvc/?fewReq=:B:JVo+NTc0PiJyOTYqNCJtYDk0NT40NSJ3bWNqZXBxdmE5ZTxlNGIxYD08ZT01M2U2NGY8MzZmZjFnYGU1ZmVgYmdiMz1nMGY2NyJwOTUzPD0wNDYxPTUidW1gOTI8QUNDUkN8NDY2PTE2KTI8QUNDUkw1NDY2PTE2InZndHA5Imc5NzcibGBoOTQ=&url=http%3a%2f%2fwww.sbri.fr%2fuser%2f1453 >s://sbri.fr/public-profile/63/single-member/
